HC-46 (CW-140 Series)

CW-142-017M-3171

Cold Weld HC-46 Wire Leads Hook Mounts or C-Clip

Product Specifications

General Parameters:
Post/Lead Dia.: .018
Grd. Pin: No
Lead Lgth. (+/- Tol.): .455+/-.015
Mount Information:
Center Lead Type & Ht.: N/A
Contact Area Dim.: .016 Slot & .050 R.
Mount To Mount: .192 Ref.
Mount Ht.: .406+/-.020
Thk. x Wdth.: .006 x .046
Temp. & Mat'l.: S.S.
